SPECS
GENERAL
-
Dimensions (WxDxH)20.2 in x 8.6 in x 14.3 in – with stand
-
Display TypeLED-backlit LCD monitor / TFT active matrix
-
Aspect Ratio16:9
-
Native ResolutionFull HD (1080p) 1920 x 1080 at 60 Hz
-
Pixel Per Inch103 ppi
-
Contrast Ratio1000:1 / 2000000:1 (dynamic)
-
Color Support16.7 million colors
-
Controls & AdjustmentsBrightness, contrast, H/V position, input select, phase, clock
-
Horizontal Viewing Angle+85 / -85
-
Vertical Viewing Angle+80 / -80
-
Viewable Size21.5″
-
Pixel Pitch0.248 mm
-
Panel TypeTN
-
Brightness250 cd/m²
-
Horizontal Refresh Rate30 – 81 kHz
-
Backlight TechnologyWLED
-
Video Bandwidth205 MHz
-
Vertical Refresh Rate50 – 75 Hz
-
ManufacturerLenovo
POWER DEVICE
-
Nominal VoltageAC 120/230 V
-
Frequency Required50/60 Hz
-
Power Consumption Operational23 Watt
-
Power Consumption Stand by0.5 Watt
-
Power Consumption Sleep0.5 Watt
CHASSIS
-
Built-in DevicesUSB 2.0 hub
POWER
-
Power Supplyinternal
-
Energy ClassClass A
-
Energy Consumption per Year29.2 kW
-
Power Consumption (On mode)20.01 Watt
-
On / Off SwitchNo
MISCELLANEOUS
-
Compliant StandardsFCC Class B certified, MPR II, VESA DPMS, VESA FPMPMI, VESA EDID, RoHS, ISO 9241-307, China Energy Label Level 1, TUV GM, DDC-2B/CI, UL Environmental SPC Gold
-
Controls & AdjustmentsH/V position, brightness, clock, contrast, input select, phase
-
Colorbusiness black
-
Mounting Kitoptional
-
Flat Panel Mount Interface100 x 100 mm
DISPLAY
-
Image Brightness250 cd/m2
-
Image Aspect Ratio16:9
-
Image Contrast Ratio1000:1
-
Video Bandwidth205 MHz
-
Video Format1080p (Full HD)
-
TypeLED-backlit LCD monitor
ENVIRONMENTAL STANDARDS
-
EPEAT CompliantEPEAT Gold
-
ENERGY STAR CertifiedYes
MECHANICAL
-
Swivel Angle90
-
Rotation Angle90
-
Height Adjustment4.3 in
-
Tilt Angle-5/+30
-
Display Position AdjustmentsHeight, pivot (rotation), swivel, tilt
-
Image Aspect Ratio16:9
DIMENSIONS & WEIGHT
-
Dimensions & Weight DetailsWith stand – width: 20.2 in – depth: 8.6 in – height: 14.3 in – weight: 10.9 lbs
Without stand – width: 20.2 in – depth: 2.2 in -
Width20.2 in
-
Depth8.6 in
-
Height14.3 in
-
Weight10.93 lbs
ENVIRONMENTAL PARAMETERS
-
Min Operating Temperature32 °F
HEADER
-
BrandLenovo
-
Product LineLenovo ThinkVision
-
ModelLT2223p
-
Packaged Quantity1
-
CompatibilityPC
CABLE DETAILS
-
TypeUSB cable, VGA cable
-
Included Qty1
-
Length6 ft
DIMENSIONS & WEIGHT DETAILS
-
Width20.2 in
-
Depth2.2 in, 8.6 in
-
Height14.3 in
-
Weight10.9 lbs
INTERFACES
-
TypeDisplayPort, HDMI, USB 2.0 downstream, USB 2.0 upstream, VGA
GENERAL
-
ManufacturerLenovo
