Monitor Specifications
Dimensions | Depth | 200.0 mm (7.87 in.) |
Height | 402.7 mm (15.85 in.) | |
Width | 539.8 mm (21.25 in.) | |
Stand | Tilt range | Range: -5° ~22° |
VESA mount | Supported (UL&GS approved) | 100 mm x 100 mm (3.94 in. x 3.94 in.) |
Image | Viewable image size | 604.47 mm (23.8 in.) |
Maximum height | 296.35 mm (11.67 in.) | |
Maximum width | 526.85 mm (20.74 in.) | |
Pixel pitch | 0.2058 mm (0.01 in.) | |
Power input | Supply voltage | 100-240V AC |
Max supply current | 1.5A | |
Power consumption
Note: Power consumption figures are for the monitor and the power supply combined |
Normal operation
Standby/Suspend |
<31 W (Max) <20 W (Typical) <0.5 W <0.3 W at 100VAC and 240VAC |
Video input (DP) | Interface | DP |
Input signal | VESA TMDS (Panel Link™) | |
Horizontal addressability | 2560 pixels (max) | |
Vertical addressability | 1440 lines (max) | |
Clock frequency | 300 MHz | |
Video input (Digital) | Interface | HDMI |
Input signal | VESA TMDS (Panel Link™)/HDMI | |
Horizontal addressability | 2560 pixels (max) | |
Vertical addressability | 1440 lines (max) | |
Clock frequency | 300 MHz | |
Communications | VESA DDC/CI | |
Supported Display Modes | Horizontal frequency | 30 kHz – 114 kHz |
Vertical frequency | 48 Hz – 75 Hz | |
Native Resolution | 2560 x 1440 at 60 Hz | |
Temperature | Operating | 0° to 40° C (32° to 104° F) |
Storage | -20 to 60° C (-4° to 140° F) | |
Shipping | -20 to 60° C (-4° to 140° F) | |
Humidity | Operating | 10% to 80% non-condensing |
Storage | 5% to 95% non-condensing | |
Shipping | 5% to 95% non-condensing |
